GLS-80 DUAL
10" LINE ARRAY
The GLS-80 is a dual 10-inch line array speaker system meticulously crafted for medium and large-sized venues and live performances. It integrates advanced acoustic design and engineering manufacturing techniques, dedicated to providing outstanding sound performance in various complex acoustic environments.
STABLE CHARACTERISTICS
The system is equipped with two high-performance 10-inch woofer units, which are made of high-strength paper cone composite materials and feature a long stroke design. They have excellent power handling capacity and low-frequency response characteristics, maintaining stable performance even under continuous high-load operation.
BOX STRUCTURE
The cabinet employs a trapezoidal geometry optimized for fluid dynamics and acoustics, facilitating tightly coupled vertical arrays while suppressing internal standing waves. Its finely polished front baffle is fitted with a metal mesh grill that combines aesthetic appeal with practical protection against dust, moisture, and impact in demanding environments.
SCENE DIVERSITY
Throughout the entire R&D process, the GLS-80 underwent hundreds of hours of field testing, covering various typical acoustic environments such as indoor theaters, open-air squares, and transportation hubs, fully verifying its adaptability under conditions of long reverberation time, high background noise, and complex spatial structures.
YOU DESERVE A TRY
For modern audio systems that require a balance between sound quality, efficiency and reliability, the GLS-80 represents a solution that combines technical depth and practical value, and is becoming the preferred device for an increasing number of professional users.
Power of GLS-80
GLS-80
Design and Acoustics
The GLS-80 and GLS-90 have the same pure and powerful sound characteristics, but are more lightweight and compact in structural design. Both adopt an array layout with a 10 ° angle between units, and the mature horizontal directional control technology of CRAZY DANCE brand can accurately control the coverage range of the sound field, concentrate the sound energy and project it to the audience area, effectively solve the acoustic challenges and environmental noise interference problems in outdoor environments, improve auditory clarity and reduce sound pollution to surrounding areas.
GLS-80 Dual 10 inch Line Array Speaker System acoustic performance Frequency response (-10 dB): 65 Hz -20 kHz Provides complete coverage from solid low frequencies to delicate high frequencies, with specially optimized mid frequency vocal performance and high frequency extension. Maximum Sound Pressure Level (SPL): 132 dB High sound pressure output capability, with sufficient dynamic margin, to meet the main sound amplification and high standard language amplification needs of medium-sized venues. Coverage angle: 110 ° (horizontal) × 10 ° (vertical) Wide horizontal diffusion ensures uniform lateral sound field coverage, while narrow vertical control effectively suppresses unnecessary reflections, improving speech clarity and sound image localization accuracy. Drive unit system High frequency unit: 1 × 2.5 "compression driver Adopting titanium alloy diaphragm and phase optimization design, the high-frequency response is delicate and smooth, with excellent transient performance, suitable for precise reproduction of human voice and instrument details. Low frequency unit: 2 × 10 ″ (260mm) bass unit Equipped with a 65mm (2.5 ") large voice coil and a long stroke magnetic circuit system, it provides strong and controllable mid to low frequency energy output with low distortion and fast dynamic response.
